2D Semiconductor More Brittle Than Expected

Rice University researchers show how tiny flaws can initiate catastrophic cracking for MoSe2 under strain

A nanomechanical device designed by Rice University scientists to measure the strength of MoSe2.

Scientists at Rice University in the US  have discovered that  2D semiconducting MoSe2, a material being eyed for flexible electronics and next-generation optical devices, is more brittle than they expected.

Led by materials scientist Jun Lou, the Rice team tested the tensile strength of 2D, semiconducting MoSe2 and discovered that flaws as small as one missing atom can initiate catastrophic cracking under strain. The team's report appears this month in Advanced Materials.

The finding may cause industry to look more carefully at the properties of 2D materials before incorporating them in new technologies, he said.

"It turns out not all 2D crystals are equal," said Lou, a Rice professor of materials science and nanoengineering. "Graphene is a lot more robust compared with some of the others we're dealing with right now, like this MoSe2. We think it has something to do with defects inherent to these materials."

The defects could be as small as a single atom that leaves a vacancy in the crystalline structure, he said. "It's very hard to detect them," he said. "Even if a cluster of vacancies makes a bigger hole, it's difficult to find using any technique. It might be possible to see them with a transmission electron microscope, but that would be so labor-intensive that it wouldn't be useful."

MoSe2 is a dichalcogenide, a 2D semiconducting material that appears as a graphene-like hexagonal array from above but is actually a sandwich of metallic atoms between two layers of chalcogen atoms, in this case, selenium. MoSe2 is being considered for use as transistors and in next-generation solar cells, photodetectors and catalysts as well as electronic and optical devices.

Lou and colleagues measured the material's elastic modulus, the amount of stretching a material can handle and still return to its initial state, at 177.2 (plus or minus 9.3) gigapascals. Graphene is more than five times as elastic. They attributed the large variation to pre-existing flaws of between 3.6 and 77.5 nanometers.

Its fracture strength, the amount of stretching a material can handle before breaking, was measured at 4.8 (plus or minus 2.9) gigapascals. Graphene is nearly 25 times stronger.

Part of the project led by Rice postdoctoral researcher Yingchao Yang required moving MoSefrom a growth chamber in a chemical vapour deposition furnace to a microscope without introducing more defects. Yang solved the problem using a dry transfer process in place of a standard acid washing that would have ruined the samples.

To test samples, Yang placed rectangles of MoSe2 onto a sensitive electron microscope platform invented by the Lou group. Natural van der Waals forces held the samples in place on springy cantilever arms that measured the applied stress.

Lou said the group attempted to measure the material's fracture toughness, an indicator of how likely cracks are to propagate, as they had in an earlier study on graphene. But they found that pre-cutting cracks into MoSe2 resulted in it shattering before stress could be applied, he said.

"The important message of this work is the brittle nature of these materials," Lou said. "A lot of people are thinking about using 2D crystals because they're inherently thin. They're thinking about flexible electronics because they are semiconductors and their theoretical elastic strength should be very high. According to our calculations, they can be stretched up to 10 percent.

"But in reality, because of the inherent defects, you rarely can achieve that much strength. The samples we have tested so far broke at 2 to 3 percent (of the theoretical maximum) at most," Lou said. "That should still be fine for most flexible applications, but unless they find a way to quench the defects, it will be very hard to achieve the theoretical limits."

The research was supported by the Air Force Office of Scientific Research, the Welch Foundation, the Department of Energy Office of Basic Energy Sciences, the National Science Foundation and the National Science Foundation of China.
